Series VV

From small berry bushes to modern vineyards and orchards to tall cider fruit trees, the VV series covers a wide range of cultivations.

The traditional drive via PTO shaft makes it possible to use these blowers with any type of tractor.

Using modern air test benches specially designed for this purpose, we have succeeded in developing ingenious cross-flow blowers that have a uniform and symmetrical air outlet.

This series is particularly popular in modern cultivations.

THOUGHT-OUT & SPOT-ON
the modern VV-blowers
Blower structure

The front air suction of these hot-dip galvanized cross-flow blowers ensure a precise application of the active substance and prevent dirt and leaves being sucked into the air flow, as is usually the case with backside air suctions. The blowers are also available powder-coated or made of stainless steel.

Ventilator

The self-developed ventilators made of light metal enable efficient use with the lowest noise level and, in contrast to ventilators made of plastic, with little effort. The integrated centrifugal clutch was designed so that it opens easily at a low speed of approx. 250 rpm.

Gearbox

The new generation of gearboxes is always equipped with a preselection transmission, which enables the two speed levels to be easily engaged. The use of high-quality cylindrical roller bearings, in contrast to conventional ball bearings, promise greater force absorption and a longer service life.

Nozzles

The double-headed nozzle holders (installed as standard) are always equipped with bayonet locks and ensure that the nozzles can be dismantled quickly and easily without any additional tools in the field. Always made of brass and equipped with a drip stop system, the individual nozzle holders can also be individually adjusted on the nozzle rods.

Models of the VV-series

60 VV
60 VV
60 cm | 24"
≤ 32.000 m³/h
2,50
2,50
10
70 VV
70 VV
70 cm | 28"
36.000 | 52.000 m³/h
3,00
3,00
12
81 VV (V15)
81 VV (V15)
81 cm | 32"
43.000 | 64.000 m³/h
3,50
3,50
16
81 VV (V14)
81 VV (V14)
81 cm | 32"
43.000 | 64.000 m³/h
4,50
3,50
16
81 VV-HS
81 VV-HS
81 cm | 32"
43.000 | 64.000 m³/h
4,50
3,50
16
91 VV
91 VV
91 cm | 36"
56.000 | 84.000 m³/h
5,00
4,00
18
Ventilator Air volume Max. plant height Max. row spacingd Number of nozzles
